ADAM Audio F7 Active Studio Monitor

F7

Nearfield Monitor
SOS Award
SOS Award
Winner
MIPA 2013
MIPA 2013
Winner
Beat
Beat
Empfehlung der Redaktion
ProSoundNetwork
ProSoundNetwork
Best of Show Winner

ADAM F7

The F7 offers all the features you want to see in a professional studio monitor: a broad frequency range (44Hz – 50kHz) plus comprehensive control.

The monitor is equipped with a Room Equalizer for high (> 5kHz) and low (< 300 Hz) frequencies and an overall volume control on the rear panel. A high pass filter (to be used in conjunction with a subwoofer) and XLR/TRS/RCA inputs complete the professional functions of the F7.

The F7 is driven by two A/B class amplifiers with 100W RMS / 140W Music. This helps the monitor to provide a vibrant, deep bass and a maximum SPL of 109dB per pair. The reproduction of dynamically challenging tracks should not be a problem with this powerhouse.

German Handmade Precision X-ART Tweeter

7“ Woofer (Glass fibre/paper)

Amp. Power RMS / Music: 100 W / 140 W

Frequency Response: 44 Hz - 50 kHz

Max. SPL Per Pair at 1 m: ≥109 dB

STATE OF THE ART TECHNOLOGY

ADAM Audio monitors have earned a worldwide reputation as the preeminent tool for sound engineers based on technological innovations that we’ve established in the field of loudspeaker technology.

Approved BY OUR PROFESSIONAL COMMUNITY

Given their balance of sonic virtues, and taking ease of use into account, I must conclude that the ADAM F7 deserves a very enthusiastic recommendation.
Chris Bryant
HifiCritic
The briskness that comes out of these tiny speakers is very exciting. The X-ART tweeter with its extended high frequency range does a perfect job here. The bass response is surprisingly powerful in an utterly unobtrusive way. These monitors offer great sound for little money, a feature one can only recommend!
Lennart Jeschke
Recording
If you have always aspired to Adam monitors but found them beyond your budget, you may well find the F5s are just what you need, with the option of going for the F7s if you need something for a slightly larger room. It could just be that Adam have come up with a serious contender for ‚best in class‘ with the F5s.
Paul White
Sound on Sound

F7 in use

Press Reviews

Tape Op [English]
Download
PDF (594 KB)
Sound:Check México [Spanish]
Download
PDF (4.7 MB)
HIFI CRITIC [English]
Download
PDF (178 KB)
MIX [English]
Download
PDF (847 KB)
Future Music [English]
Download
PDF (1.4 MB)
DJ Magazine [English]
Download
PDF (1.1 MB)
Pro Audio Asia [English]
Download
PDF (1.2 MB)
Beat [German]
Download
PDF (225 KB)
Interface [Dutch]
Download
PDF (147 KB)
Audio [German]
Download
PDF (4 MB)
Resident Advisor [English]
Sound On Sound Brasil [portuguese]
Download
PDF (3.9 MB)
Sound On Sound [English]
Download
PDF (1.6 MB)
Pro Audio Review [English]
Download
PDF (369 KB)
MusicTech [English]
Download
PDF (890 KB)
dv247.com [English]
Professional Audio [German]
Download
PDF (1.5 MB)
KR Home-Studio [French]
Download
PDF (351 KB)
Recording Magazine [English]
Download
PDF (2.6 MB)

Features & Benefits

Product Feature
Benefit to the customer
X-ART tweeter, handmade in Berlin

– Allows longer operation with fewer signs of fatigue – Their breakup is prevented by the folded diaphragms, distortions are effectively reduced to a minimum – Advanced dynamic range due to acoustically effective diaphragm surface that is 2.5 times bigger (compared to a classic tweeter according to the piston principle)

The air velocity ratio of 4:1 during the sound generation by folded X-ART membrane

Direct, fast response in the high-range even with complex transients

Lightweight glass fiber/paper sandwich construction of the woofers

Excellent transient response even at high sound levels without breakup of the diaphragm

Vertical 2-way system with 7” woofer

High resolution of the stereo image

Spacious bass reflex ports on the front

– Bass reproduction with very low compression – Allows positioning close to walls

Linear frequency response of 44 Hz to 50 kHz

Unbiased reproduction in a wide frequency band

Maximum peak sound pressure per pair in 1 m ≥ 109 dB

Powerful, compression-free sound reproduction even at very high sound levels

Simple, stepless room acoustic adjustments over 2-band EQ and high pass filter

Allows optimal adaptation to acoustically difficult listening environments or individual preferences

Analog inputs over XLR/jack combination sockets and RCA

Optimized for balanced and unbalanced line signals

Auto Standby Mode

Energy saving when not in use

Acoustically optimized cabinet geometry

Reduction of unwanted reflections on the cabinets

Compact cabinet dimensions

Fits every desktop

Easily mounted on walls with original ADAM Audio wall mount (optional)

Space saving positioning at any height

2 years warranty

Full repair service if required

Technical Data

Woofer

Number1
Basket Ø7" (177 mm)
Voice Coil Ø1.5" (37 mm)
Cone MaterialGlass fiber/paper

Tweeter

Number1
TypeX-ART
Diaphragm Area3 inch² (1848 mm²)
Equiv. Diaphragm Ø1.5" (42 mm)
Velocity Transform Ratio4:1

Built-in Amplifiers

Woofer1
TypeA/B
Amp. Power RMS / Music60 W / 85 W
Tweeter1
TypeA/B
Amp. Power RMS / Music40 W / 55 W

Control Panel

Input Sensitivity-∞ to +6 dB
High Shelf EQ > 5 kHz±6 dB
Low Shelf EQ < 300 Hz±6 dB

Input Connectors

AnalogXLR / RCA / TRS

General Data

Frequency Response44 Hz - 50 kHz
Max. SPL per pair at 1 m≥109 dB
Crossover Frequencies2600 Hz
Weight19.8 lb (9 kg)
Magnetically ShieldedNo
Height x Width x Depth12.5" (321 mm) x 9" (225 mm) x 10.5" (266 mm)
Warranty2 years
Delivery ContentsPower cord, manual
