T10S

Subwoofer
ADAM Audio T10S Subwoofer

ADAM Audio T10S

The T10S is a powerful yet compact active subwoofer, designed to extend the bass response of any nearfield studio monitor. However, the subwoofer’s performance, features and connectivity are engineered specifically to complement ADAM Audio’s T5V and T7V speakers.

Equipped with a down-firing 10˝ woofer and a 130 W Class-D amplifier, the T10S’ frequency response ranges from 28 Hz to 120 Hz and offers an impressive max. SPL of 104 dB. An internal adjustable two-channel crossover allows calibration of the bass signal and provides optimal performance of the total system. The options at the rear of the subwoofer allow for varied adjustments which compensate for room acoustics or they offer more control for satellites attached.

While reciting the T Series design language, the T10S is one of the most compact subwoofers in its class, which allows it to be easily integrated in any studio environment. The acoustic performance was optimized by four high grade flexible rubber feet that prevent the sound from exciting the floor and a spacious rear facing bass reflex port for an optimized airflow.

10“ Subwoofer (paper)

Amp. Power RMS: 130 W

Frequency Response: 28 Hz - 120 Hz

Max. SPL at 1 m: ≥104 dB

Optimized for T Series studio monitors

360 Degree View

Backplate printing may vary in different countries.

Press Reviews

DJCity [English]
ProSound.iXBT.com [Russian]
uptone.pl [Polish]

Features & Benefits

Product Feature
Benefit to the customer
Linear bass reproduction down to 28 Hz

Ideal addition to smaller nearfield monitors, specifically the T Series

Maximum Peak sound pressure in 1 m ≥ 104 dB

Powerful, compression-free sound reproduction even at very high sound levels

High efficiency PWM amplifier

Low-distortion amplification at both low and high volume levels

Special 10" woofer with paper diaphragm

Unrestricted bass reproduction for low-fatigue operation

Easy manual or automatic (de-)activation (via optional foot switch)

If desired, monitoring is possible without the low frequencies

Crossover optimized for T Series studio monitors

Takes into account the specific characteristics of the T5V and T7V studio monitors for the best result

Analog XLR / RCA in- and outputs

Optimized for balanced and unbalanced line signals

Small footprint

Flexible positioning in room for optimal sound results

2 years warranty with optional extension to 3 years with the registration of the product

Full repair service if required for 5 years

Technical Data

Subwoofer (down-firing)

Number1
Basket Ø10" (260 mm)
Voice Coil Ø38mm / 1.5"
Cone MaterialPaper

Built-in Amplifiers

Subwoofer1
TypePWM
Amp. Power RMS130 W

Control Panel

Crossover Frequency80 Hz / 120 Hz / Bypass
Phase Inversion0° / 180°

Connectors

Analog InputsXLR / RCA
Analog OutputsXLR / RCA

General Data

Frequency Response28 Hz - 120 Hz (@ -6 dB)
THD > 60 Hz0.6%
Max. SPL at 1 m (hemisphere)≥104 dB
Max. Power Consumption190 W
Input Sensitivity +4 dBu / -10 dBV
PanelRear
BypassYes, via footswitch (not included)
StandbyYes, activates after 15 minutes with no incoming signal
Weight27 lb (12.2 kg)
Height x Width x Depth15.4" (390 mm) x 12.5" (318 mm) x 16.25" (413 mm)
Warranty5 years (2 years warranty plus 3 years optional with product registration) (2 years warranty plus 3 years optional with product registration)
Delivery ContentsPower cord, Quick Start Guide, Welcome Card
