ADAM Audio S2V Studio Reference Monitor

S2V

Nearfield Monitor

ADAM S2V

The S2V is a classic two-way nearfield monitor designed for use in small-to-medium-sized control rooms.

The 7-inch bass driver, newly created from the ground up for the S Series, covers frequencies ranging from 35 Hz to 3 kHz and delivers a powerful, distortion-free low-end with a wide dynamic range. The carefully refined S-ART tweeter, handbuilt as ever at the ADAM Audio factory in Berlin, works seamlessly in tandem with the newly developed HPS waveguide, creating absolutely precise imaging within a generously proportioned sweet spot.

The S2V’s compact dimensions belie its impressive power. A 300 W Class D amplifier drives the woofer while a 50 W Class A/B unit handles the S-ART tweeter; the combined output produces SPLs of up to 120dB per pair.

The S Series’ custom-designed DSP optimizes the loudspeaker crossovers to create linear responses for the entire range, as well as providing user equalization and in-room tuning/voicing functions. The DSP also handles the limiter-based high-frequency driver protection, processes the signals from the AES3 digital inputs, and will in time facilitate various expansion options. Software updates can be carried out with ease via the associated USB port, which also allows users to connect computers and control the speakers’ DSP functions via a software front-end.

With its highly accurate frequency response and balanced, razor-sharp imaging, the S2V allows users to pinpoint even the most subtle audio details, making it an ideal choice for use in demanding studio environments.

German Handmade Precision S-ART Tweeter with HPS Waveguide

7“ Woofer (Hexacone)

Cumulated Amp. Power RMS: 350 W

Frequency Response: 35 Hz - 50 kHz

Max. SPL Per Pair at 1 m: ≥120 dB

AES3 Digital Inputs And Various Expansion Options

Features & Benefits

Product Feature
Benefit to the customer
S-ART tweeter, handmade in Berlin and manufactured to the tightest tolerances in ADAM Audio’s history
  • Allows longer operation with fewer signs of fatigue
  • Their breakup is prevented by the folded diaphragms, distortions are effectively reduced to a minimum
  • Advanced dynamic range due to acoustically effective diaphragm surface that is 2.5 times bigger (compared to a classic tweeter according to the piston principle)
The air velocity ratio of 4:1 during the sound generation by folded S-ART membrane

Direct, fast response in the high-range even with complex transients

Newly designed HPS waveguide, milled from a solid block of aluminum
  • Makes dispersion more consistent and imaging more stable over a wider area
  • Reduction of early reflections on the surfaces of, e.g. mixing consoles, desks, etc.
Custom-built Extended Linear Excursion (ELE) bass drivers

Accurate audio reproduction at an extremely high resolution thanks to the precision-designed relationship between its low weight, optimized inner damping and highly rigid HexaCone membrane, in conjunction with a basket which has been developed to eliminate unwanted resonance and distortion

Custom-designed Symmetrical Magnet Assembly (SMA)
  • Allows the voice coil a maximum excursion three times greater than that offered by previous designs, with an extended, symmetrical magnetic field ensuring linear, low-distortion operation
  • Power compression effects are prevented by an intelligent self-cooling system
Vertical 2-way system with 7” woofer

Very high resolution of the stereo image

Spacious bass reflex ports on the front
  • Bass reproduction with very low compression
  • Allows positioning close to walls
Highly efficient PWM ICE Power amplifier for the woofer coupled with an A/B amplifier for S-ART tweeter

Low-distortion amplification at both low and high volume levels

Linear frequency response of 35 Hz to 50 kHz

Unbiased reproduction in a wide frequency band

Maximum peak sound pressure per pair in 1 m ≥ 120 dB

Powerful, compression-free sound reproduction even at very high sound levels

Custom DSP engine
  • Perfect crossovers for optimal frequency response and maximum dynamic range
  • EQ options and presets for in-room optimization
  • Limiter-based amp protection, AES3 digital inputs and board connectors for future expansion options, together with a USB connector for software upgrades and computer-based control
Analog XLR input

Optimized for balanced line signals

Acoustically optimized and weightily constructed cabinets

Reduction of susceptibility to vibrations and unwanted edge-diffraction effect

2 years warranty with optional extension to 3 years with the registration of the product

Full repair service if required for 5 years

Technical Data

Woofer

Number1
Basket Ø7" (178 mm)
Voice Coil Ø1.5" (39 mm)
Cone MaterialHexaCone

Tweeter

Number1
TypeS-ART
Diaphragm Area4 inch² (2420 mm²)
Equiv. Diaphragm Ø2" (56 mm)
Velocity Transform Ratio4:1
Diaphragm Weight0.17 g
WaveguideHPS

Built-in Amplifiers

Number2
Woofer1
TypePWM
Amp. Power RMS300 W
Tweeter1
TypeA/B
Amp. Power RMS50 W

Control Options

Input SensitivityAdjustable
Parametric EQs6
Room Compensation High-Shelf EQ1
Room Compensation Low-Shelf EQ1
Preset Memories5
Delay0 ms to 5 ms

Input Connectors

AnalogXLR
Input Impedance48 kOhm
Max. Input Level+24 dBu
DigitalAES3

General Data

PanelRear
Frequency Response35 Hz - 50 kHz
THD > 100 Hz≤0.4 %
Max. SPL per pair at 1 m≥120 dB
Crossover Frequencies3 kHz
Max. Power Consumption230 W
Weight24.2 lb (11.0 kg)
Height x Width x Depth13,6" (346 mm) x 8,7" (222 mm) x 13,3“ (338 mm )
Warranty5 years (2 years warranty plus 3 years optional with product registration)
Delivery ContentsPower cord, Manual
