ADAM Audio A3X Studio Monitor

A3X

Nearfield Monitor

ADAM A3X

Particularly interesting for the quality-conscious user on a tight budget is the most compact monitor of the AX-Series, the A3X. Specially designed for studio environments with limited space, the A3X easily meets professional requirements. Three-dimensional spatial representation, a controlled, deep bass response and accurate sound reproduction, especially in the critical areas between 200 and 400 Hz, make it the first choice for smaller, even mobile studio setups.

With the A3X, analytical listening is possible without taking away musical enjoyment. Its excellent transient response and ability to easily play very dynamic tracks in all musical genres let it clearly stand out from comparable monitors in this price range.

Stereolink

The ‘Stereolink’ is a useful feature for desktop DAWs. Two additional input and output jacks for the second stereo channel allow you to control the volume for both monitors using the volume control of only one loudspeaker. The volume control of the other monitor only affects its own volume in order to easily compensate for differences in listening distance. Unlike the typical master-slave configuration, each A5X monitor is fully equipped and can function either as a master or a slave unit.

German Handmade Precision X-ART Tweeter

4.5 “ Woofer (Carbon Fiber)

Amp. Power RMS / Music: 50 W / 80 W

Frequency Response: 60 Hz - 50 kHz

Max. SPL per pair at 1 m: ≥106 dB

STATE OF THE ART TECHNOLOGY

ADAM Audio monitors have earned a worldwide reputation as the preeminent tool for sound engineers based on technological innovations that we’ve established in the field of loudspeaker technology.

Approved BY OUR PROFESSIONAL COMMUNITY

In a small to medium size setup, it will be an excellent main monitor. In a larger setup, it will be an excellent alternative to bigger speakers, providing accurate near-field information, and offering relief from ear fatigue that a large system can inflict.
Lorenz Rychner
Recording Magazine (US)
For mobile setups or studios with limited budgets for monitors, the ADAM A3X is an excellent new option.
Steve Silverstein
TapeOp
Although they are small, the size of the audio image belies their size. The overall feel is effortless and solid, with a suprising degree of weight in the bass end.
Huw Price
MusicTech
The low-frequency response is very powerful, consider¬ing their size, and the X-ART tweeter produces a very detailed sound. (...) The ADAM A3X is without a doubt the best compact speaker in this price range.
Red Led
audiofanzine.com
I’ve used various monitors for my computer work before, but never of the caliber of the A3X series. Before these, I would have to redo my mixes significantly when transi¬tioning from the small cheapies to the big ‚real ones‘. The ADAM Audio A3X’s save me a step by providing both great sound in a compact format and by changing mun¬dane audio task-work into a quality listening experience. (...) Highly recommended.
Jon Chappell
Harmony Central

A3X in use

Press Reviews

Hörerlebnis [German]
Download
PDF (136 KB)
audio fanzine.com [English]
Download
PDF (121 KB)
Recording Magazine [English]
Download
PDF (110 KB)
Pro Audio Review [English]
Download
PDF (108 KB)
Tape Op#79 [English]
Download
PDF (1.2 MB)
Interface [Dutch]
Download
PDF (122 KB)
Future Music [English]
Download
PDF (2.3 MB)
MusicTech [English]
Download
PDF (1.2 MB)
Professional Audio [German]
Download
PDF (667 KB)
Harmony Central [English]
Download
PDF (114 KB)
Monitor Scandinavia Mag [Danish]
Download
PDF (2.3 MB)

Features & Benefits

Product Feature
Benefit to the customer
A3X –the full featured compact monitor from the AX Series

– Affordable entry into the high end home recording area for the quality conscious user – The small dimensions make is possible to also use it “on the road”

X-ART tweeter, handmade in Berlin

– Allows longer operation with fewer signs of fatigue – Their breakup is prevented by the folded diaphragms, distortions are effectively reduced to a minimum – Advanced dynamic range due to acoustically effective diaphragm surface that is 2.5 times bigger (compared to a classic tweeter according to the piston principle)

The air velocity ratio of 4:1 during the sound generation by folded X-ART membrane

Direct, fast response in the high-range even with complex transients

Lightweight glass fiber membrane of the woofers

Excellent transient response even at high sound levels without breakup of the diaphragm

Vertical 2-way system with 4.5” woofer

High resolution of the stereo image

Linear frequency response of 60 Hz to 50 kHz

Unbiased reproduction in a wide frequency band

Maximum peak sound pressure level per pair in 1 m ≥106 dB

Powerful, compression free sound reproduction even at very high sound levels despite compact design

Tweeter-Gain-Controller

Allows optimal adaptation to acoustically difficult listening environments or individual preferences

Stereolink function (Cinch cable contained in the delivery contents)

Simple and symmetric volume control on the front panel

Analog XLR and RCA inputs

Optimized for balanced and unbalanced line signals

Acoustically optimized cabinet geometry

Reduction of unwanted reflections on the cabinets

Directional sound radiation in vertical plane

Reduction of early reflections on the surfaces of, e.g. mixing consoles, desks, etc.

Volume control and on/off switch on the front

Very easy to use

Very compact cabinet dimensions

Fits every desktop

Easily mounted on walls with original ADAM Audio wall mount (optional)

Space saving positioning at any height

2 years warranty with optional extension to 3 years with the registration of the product

Full repair service if required for 5 years

Technical Data

Woofer

Number1
Basket Ø4.5" (120 mm)
Voice Coil Ø1" (25 mm)
Cone MaterialCarbon Fiber

Tweeter

Number1
TypeX-ART
Diaphragm Area4 inch² (2420 mm²)
Equiv. Diaphragm Ø2" (56 mm)
Velocity Transform Ratio4:1
Diaphragm Weight0.17 g

Built-in Amplifiers

Woofer1
TypeA/B
Amp. Power RMS / Music25 W / 40 W
Tweeter1
TypeA/B
Amp. Power RMS / Music25 W / 40 W

Control Panel

Input Sensitivity-∞ to +14 dB
Tweeter Gain±4 dB

Input Connectors

AnalogXLR / RCA

General Data

Frequency Response60 Hz - 50 kHz
THD 90 dB / 1 m > 100 Hz≤0.8 %
Max. SPL with sine wave acoustic 100 Hz to 3 kHz at 1 m≥98 dB
Max. SPL per pair at 1 m≥106 dB
Crossover Frequencies2800 Hz
Input Impedance10 kOhm
PanelFront
StereolinkYes
Weight10.1 lb (4,6 kg)
Magnetically ShieldedNo
Height x Width x Depth10" (252 mm) x 6" (150 mm) x 7.5" (185 mm)
Warranty5 years (2 years warranty plus 3 years optional with product registration)
Delivery ContentsCinch-cable, power cord, manual
