ADAM Audio Subwoofer Sub7

Sub7

Subwoofer

ADAM Sub7

The Sub7 has been designed to complement smaller monitors such as the AX-Series. Its small footprint allows for easy placement, even in small environments. The included remote control facilitates volume changes or crossover frequency adjustments from your favorite listening position.

The Sub7 is equipped with both balanced (XLR) and unbalanced (RCA) input and output connectors, allowing the Sub7 to be used in home or studio environments. Numerous control options allow for many and varied adjustments to room acoustics or the satellites used.

The low cutoff frequency of 32Hz (-3dB) enables this subwoofer to reproduce even the lowest frequencies with accuracy and realism.

7“ Subwoofer (paper)

Amp. Power RMS / Music: 140 W / 210 W

Frequency Response: 32 Hz - 150 Hz

Max. peak SPL at 1 m: ≥107 dB

Remote Control

ADAM Sub7 in use

Features & Benefits

Product Feature
Benefit to the customer
Linear bass reproduction down to 32 Hz

Ideal addition to smaller nearfield monitors

Maximum Peak sound pressure in 1 m ≥ 107 dB

Powerful, compression-free sound reproduction even at very high sound levels

High efficiency PWM amplifier

Low-distortion amplification at both low and high volume levels

Special 7" woofer with paper diaphragm

Unrestricted bass reproduction for low-fatigue operation

Easy manual or automatic (de-)activation (via optional foot switch)

If desired, monitoring is possible without the low frequencies

Upper cut-off frequency is selectable between 50 to 150 Hz

Allows optimal adaptation of the total system on the bass performance of the satellites

Connectable high-pass filter for the satellite outputs, which blocks signals below 85 Hz
  • Dolby®- Fair reproduction of film sound
  • Discharging the satellites from the low frequencies
Remote control (contained in the delivery contents)

Comfortable control in any situation

Analog XLR and RCA inputs

Optimized for balanced and unbalanced line signals

Small footprint

Flexible positioning in room for optimal sound results

2 years warranty with optional extension to 3 years with the registration of the product

Full repair service if required for 5 years

Technical Data

Subwoofer

Number1
Basket Ø7" (178 mm)
Voice Coil Ø1.5" (38 mm)
Cone MaterialPaper

Built-in Amplifiers

Subwoofer1
TypePWM
Amp. Power RMS / Music140 W / 210 W

Control Panel

EQ 80 Hz-60 to +6 dB

Input Connectors

AnalogXLR / RCA

General Data

Frequency Response32 Hz - 150 Hz
THD > 60 Hz≤1 %
Max. peak SPL at 1 m≥107 dB
Crossover Frequencies50 - 150 Hz
Input Impedance10 kOhm
PanelFront
Weight17.6 lb (8 kg)
Height x Width x Depth14.5" (370 mm) x 8" (200 mm) x 11" (280 mm)
Warranty5 years (2 years warranty plus 3 years optional with product registration) (2 years warranty plus 3 years optional with product registration)
Delivery ContentsRemote control, batteries (2 x AAA), power cord, manual
