ADAM Audio Subwoofer Sub12

Sub12

Subwoofer

ADAM Sub12

The Sub12 is a powerful subwoofer designed to extend the low frequency capabilities of any near or midfield monitoring system down to 22 Hz.

A sturdy special woofer with extended cone travel and a heavy-duty coil have been optimized for accurate reproduction from a bass reflex enclosure. The down-firing bass reflex tube avoids intrusive ventilation noise because of its generous size and shape. The PWM amplifier produces over 90% efficiency and can handle critical passages without overheating for long periods of time. An additional output allows you to cascade as many subwoofers as needed.

The Sub12 subwoofer provides a precise combination of low cutoff frequency (-3dB at 22Hz) and an undistorted high sound pressure level (115dB SPL at 1m).

12“ Subwoofer (paper)

Amp. Power RMS / Music: 200 W / 300 W

Frequency Response: 22 Hz - 150 Hz

Max. peak SPL at 1 m: ≥115 db

Sub12 in use

Press Reviews

Tape OP [English]
Download
PDF (9.2 MB)

Features & Benefits

Product Feature
Benefit to the customer
Bass reproduction down to 22 Hz

Ideal addition to nearfield and midfield monitors

Maximum Peak sound pressure in 1 m ≥ 115 dB

Powerful, compression-free sound reproduction even at very high sound levels

High efficiency PWM amplifier

Low-distortion amplification at both low and high volume levels

Special 12" woofer with paper diaphragm

Unrestricted bass reproduction for low-fatigue operation even at high volumes

Easy manual or automatic (de-)activation

If desired, monitoring is possible without the low frequencies

Additional sub output

Allows building a (double) bass array

According to downward working bass reflex tube with generous dimensions and corresponding rounding

Prevention of air turbulence noise

Crossover frequency is selectable between 50 - 150 Hz

Allows optimal adaptation of the total system on the bass performance of the satellites

Connectable high-pass filter for the satellite outputs, which blocks signals below 85 Hz
  • Dolby®- Fair reproduction of film sound
  • Discharging the satellites from the low frequencies
2 years warranty with optional extension to 3 years with the registration of the product

Full repair service if required for 5 years

Technical Data

Subwoofer

Number1
Basket Ø12" (310 mm)
Voice Coil Ø2" (50 mm)
Cone MaterialPaper

Built-in Amplifiers

Subwoofer1
TypePWM
Amp. Power RMS / Music200 W / 300 W

Input Connectors

AnalogXLR / RCA

General Data

Frequency Response22 Hz - 150 Hz
THD > 60 Hz≤1 %
Max. peak SPL at 1 m≥115 dB
Crossover Frequencies50 - 150 Hz
Input Impedance10 kOhm
PanelRear
Weight57.3 lb (26 kg)
Height x Width x Depth23.5" (600 mm) x 14" (360 mm) x 17.5" (450 mm)
Warranty5 years (2 years warranty plus 3 years optional with product registration)
Delivery contentsPower cord, manual
